Product Features:
Using the high-quality FAN, long life, high negative pressure and large flow, there is filter core with fire-proof and filtering function inside the chassis, it has long service life and good filtering effect.

Applications Fields:
Large Laser cutting, Large Laser curving.

Features:
1. Metal frame structure in body, it is durable in use.
2. Microcomputer chip control, digital display, remote control available.
3. Filter failure alarm system.
4. Multi-layer filtration and rapid purification.
5. It is equipped with observation window so you can view the service condition any time.
6. DC brushless motor made it a stable performance and long life.
7. Impeller made of special alloy material, anti-corrosion; stable and reliable in operation, large amount of absorption.
8. Dust collection and filtration, odor filtration, fire proof.
9. Long life motor ≥ 8 years

Specifications:

Model	XL-1200	XL1500	XL-2000
Flilter	4 layers	4 layers	4 layers
Filtering effect	0.3µm 99.97%	0.3µm 99.97%	0.3µm 99.97%
Weight	146kg	155kg	155kg
Dimension (LxWxH)	750x597x1535 mm	750x597x1535 mm	750x597x1535 mm
Flow (m3/h)	778	1190	1465
Noise	< 67dB	< 70dB	< 75dB
Power	870W	1300W	2000W
Voltage	AC220V	AC220V	AC380V
Fireproof Protection Network	660 x 523 x 50 mm
Bag/ Pocke Filter (22 layers)	550 x 430 mm
PP medium (Hepa) filter core	660 x 523 x 120 mm
Activate carbon Filter	660 x 523 x 100 mm

Included:
The Dust hose + Round Hood Adapter Each a 1 set
